Duplex Stainless Steel Tube Fittings manufacturer
Manufacturer of Duplex Stainless Steel Tube Fittings, compression fittings, Instrumentation Tube Fittings, stainless steel Tube Fittings, Double Ferrule Tube Fittings, Ferrule Fittings, ASTM A276 Tube Fittings in India
Manufacturer, stockist & suppliers of Duplex Stainless Steel Tube Fittings, compression fittings, Instrumentation Tube Fittings, stainless steel Tube Fittings, Double Ferrule Tube Fittings, Ferrule Fittings, ASTM A276 Tube Fittings
Divine Metal’s premium collection of Duplex Stainless Steel Tube Fittings are ideal for a diverse range of industries, including process oil and gas, petrochemical, power generation, military, pharmaceutical, and more. Divine Metal is your superior alternative to Swagelok fittings & Parker A-lok. Components are fully interchangeable with Swagelok. We offer an assortment of Duplex Stainless Steel Tube Fittings & all instrumentation compression tube fittings in a range of corrosion resistant alloy materials, including 304 stainless steel, 316 Stainless Steel, 6Mo, Alloy 400, Alloy 825, Alloy 625, Copper, Brass, Titanium and more. Similar to Parker Instrumentation fittings Divine Metal Stainless steel tube fittings work reliably on both seamless and welded-redrawn, fully annealed type 304, 316 and 316L tubing.
Contents:
- What is Duplex Stainless Steel Tube Fittings?
- Duplex Stainless Steel Tube Fittings specification
- Duplex Stainless Steel Tube Fittings features
- Duplex Stainless Steel Tube Fittings benefits
- Duplex Stainless Steel Tube Fittings price
About Divine Metal Duplex Stainless Steel Tube Fittings
S32205 / S31803
Ferrule Fitting of high quality and precision finishing are manufactured by Divine Metal are are sold under our brand Divine Metal Ferrule Fitting. We manufacture both single ferrule and double ferrule fittings. Popular brands include Swagelok and Parker. Divine Metal Duplex Stainless Steel Tube Fittings is fully interchangeable with Swagelok & Alok fittings.
Divine Metal Ferrule fitting are manufactured in Stainless steel and Alloy steel grades. Most poplular stainless steel grades include Stainless steel 304 & Stainless steel 316. Alloy steel grades include , Monel, Inconel, Alloy 600 & 825, Hastelloy 276, Duplex Steel , Super Duplex Steel, 254 SMO etc. Ferrule fittings are also manufactured in copper & brass.
Divine Metal Ferrule fitting are manufactured to sustain high pressures of upto 6000 psig. Fittings come with a product replacement warranty of 1 year and have inclusive Mill test certificate by Divine Metal.
- Excellent corrosion resistance in chloride-containing environments
- Advanced-geometry back ferrule design enhances sealing action
- Same gaugeability as traditional Divine tube fittings
- Easy installation using hand tools
- Available in sizes from 1/4 to 3/4 in.
Duplex Stainless Steel Tube Fittings specification
|
Brand name
|
Divine Metal Duplex Stainless Steel Tube Fittings
|
|---|---|
|
Tube Size
|
1/16”OD to 2”OD, 2mm OD to 50mm OD
|
|
Material Grades
|
SS 304, SS 316, Brass, Special Alloys
|
|
Thread
|
NPT, BSP, BSPT, UNF, ISO, SAE etc.
|
|
Pressure Rating
|
6000PSI for Stainless Steel, 300/1000/3000PSI for Brass
|
|
Stainless Steel
|
ASTM A276 ASME SA 479
|
|
Brass
|
ASTM B16 ASTM B 453
|
|
Material Grades
|
Stainless Steel 304, Stainless Steel 316, Brass, Special Alloys, 20#,1Cr18Ni9Ti
|
|
PTFE Standards
|
ASTM D1710, ASTM D3294
|
|
Applicable temperature
|
150-400°C
|
|
Packing Details
|
|
| Stainless Steel | Tradename | UNS no. | Werkstoff No. | Density (g/cm3) |
| Duplex | F51 / 2205, F60 | S31803 / S32205 | 1.4462 | 7.805 |
With a PREN of around 35, duplex stainless steels are generally more corrosion resistant than 304 (PREN: 19) and 316 stainless steels (PREN: 26), particularly stress corrosion cracking. Duplex stainless steel pipes and duplex fittings are generally lower in cost, as lower percentage of alloying element is used in the manufacture of duplex stainless steel. The yield strength of duplex stainless steel products is higher compared to austenitic stainless steel products, as a result of which users can purchase relatively lower thickness duplex pipes and duplex fittings.
Stainless Steel Duplex 2205 is an austenitic ferritic stainless steel that has constructive properties of both austenitic and ferritic steels. The high steel alloy has high chromium and molybdenum content which helps construct excellent mechanical properties such as uniform corrosion resistance to stress corrosion cracking and very good pitting. Duplex 2205 good welding abilities and can be welded using nearly all the techniques of stainless steel. This high steel alloy can be worked at a temperature of 600 ° F above that can cause embrittlement of the alloy. It is also resistant to marine environments, bleaching operations, closed loop water system, brackish water and food processing applications.
Specifications
| STANDARD | DUPLEX 2205 / 31803 |
|---|---|
| UNS | S32250 / S31803 |
Physical Properties
| DENSITY (G/CM 3) | 7.805 |
| DENSITY (LB/IN 3) | 0.285 |
| MELTING POINT (°C) | 1420 – 1465 |
| MELTING POINT (°F) | 2588 – 2669 |
Chemical Composition
| ELEMENT | DUPLEX 2205 | DUPLEX 31803 |
|---|---|---|
| NI | 4.50 – 6.50 | 4.50 – 6.50 |
| C | 0.030 max | 0.030 max |
| MN | 2.00 max | 2.00 max |
| P | 0.030 max | 0.030 max |
| S | 0.20 max | 0.020 max |
| SI | 1.00 max | 1.00 max |
| CR | 21.0 – 23.0 | 22.0 – 23.0 |
| MO | 2.50 – 3.50 | 3.0 – 3.5 |
| N | 0.08 – 0.20 | 0.14 – 0.20 |
| FE | 63.54 min | 63.72 min |
Duplex Stainless Steel Tube Fittings features
Features the Divine Metal® Duplex Stainless Steel Tube Fittings has been specifically designed for use on instrumentation, process and control systems, analyzers, and environmental equipment employed in chemical, petroleum, power generation, and pulp and paper plants. Divine Metal® Duplex Stainless Steel Tube Fittings have also been used extensively in other applications and industries wherever high reliability and quality are required.
Duplex Stainless Steel Tube Fittings benefits
- Duplex Stainless Steel Tube Fittings are fully interchangeable with Swagelok.
- Manufactured to an ASME Quality Certificate SPC is a feature of the QA process.
- High quality silver plated threads on nuts to ensure no galling on the body threads.
- Divine Metal Suparcase Ferrule for corrosion resistance.
- Gaugeable Bodies.
- Tube fittings supply with DIN, ISO, EN, SAE, MA certificate
- Zero leakage even under tough working conditions
- Good high-pressure/corrsion/extreme temperature resistance
- Simple to operate and save time and cost because of the usage of elastic seal
- Widely used throughout the world
- It can be reused.
- Leak-proof joints capable of satisfying high pressure vacuum and vibration application
Duplex Stainless Steel Tube Fittings price
- Brass Compression Fitting for Copper Pipe
US $0.35-8 / Unit (FOB Price) - 1/4 npt compression fitting hydraulic fittings 2 way straight male connector
US $1-100 / Piece (FOB Price) - Stainless Steel Single Double Ferrule Compression Fittings (Pipe and Tube Fittings)
EUR 3-500 / Unit (FOB Price) - male and female brass compression fitting for pipe
US $0.5-2 / Set (FOB Price) - 1/2"-2" Compression Fittings
1 Piece (Min. Order) - instrumental compression fitting
US $1-20 / Set (FOB Price) - High quality copper pipe fitting,12 compression copper fitting
1 Piece (Min. Order) - SS316L Instrumentation Compression Tube Fittings Male Female Adapter Swagelok / Parker / HYLOK Equivalent
1 Piece (Min. Order) - Brass Compression Fittings for PEX-AL-PEX Pipe
US $0.35-8 / Unit (FOB Price) - stainless steel 1/2" swagelok style compression fitting
US $15-150 / Piece (FOB Price) - Stainless Steel Compression reducing tube fitting
US $0.5-3 / Piece (FOB Price) - 316 Stainless Steel Compression Tube Fitting, 90 Degree Elbow, Tube OD x NPT Male
US $1-20 / Piece (FOB Price) - Brass compression fitting 22mm
10 Units (Min. Order) - Stainless steel double ferrule fitting high pressure compression fitting 1/4"straight fitting
US $6.00 / Piece ( Wholesale Price) - Brass Male Tee compression fittings
US $2.0-5.3 / Piece (FOB Price) - double compression fittings
10 Pieces (Min. Order) - Brass compression fittings supplier
US $0.389-0.456 / Piece (FOB Price) - Stainless steel compression tube fitting, double ferrule
US $2.5-15 / Piece (FOB Price) - 15mm Copper Compression Fittings
US $0.75-8.6 / Piece (FOB Price) - brass 12mm compression fittings
5 Pieces (Min. Order) - SS 304 Compression Tube Fittings equivalent to Swagelok : Pipe Fittings : Street Elbow
US $2-500 / Pint (FOB Price) - double ferrule compression fittings/ Brass compression fittings / Aluminum compression fittings
US $1-8 / Piece (FOB Price) - brass Imperial Double Ferrule Tube Fittings
US $2-12 / Unit (FOB Price) - Hydraulic Double Ferrule Tube Fitting/Compression Fittings
US $0.1-1 / Piece (FOB Price) - China supplier stainless steel double ferrule tube fittings fitting swagelok
US $5-50 / Piece (FOB Price) - 90 degree elbow,double ferrule elbow Tube fitting
US $0-15 / Set (FOB Price) - Double ferrule tube fitting,Union equal tee
US $2-12 / Unit (FOB Price) - double ferrule DN10 male thread ss316 union tee tube fitting
US $3.5-100.5 / Piece (FOB Price) - 3/4" double ferrule stainless steel 3 way tube fitting from Divine Metal
US $3.5-50.5 / Piece (FOB Price)
